Spray Nozzle

Fogging nozzles have a wide range of uses in a variety of industrial and commercial applications. Here are the main areas of use:

Greenhouse and Agriculture:

It is used to moisturize plants and reduce the temperature in greenhouses. It is also used in agricultural applications where moisture is critical, such as mushroom production.

Ventilation and Air Conditioning:

It is used to cool and humidify the environment in large industrial buildings, storage areas and outdoor events.

Food Storage and Processing:

It is used for humidification in cold storage and processing facilities to preserve the freshness of fruits and vegetables.

Dust Control:

It is used to prevent dust formation and improve air quality in sectors such as mining, construction and concrete production.

Special Events and Entertainment Venues:

Used to cool visitors at outdoor concerts, theme parks and other event areas.

Livestock:

It is used in poultry and cattle farms to protect animals from heat stress and increase their comfort.

Advantages

Effective Humidification and Cooling:

Fogging nozzles provide effective humidification and cooling in large areas by spraying water in fine droplets.

Low Energy Consumption:

Since it works with high pressure systems, energy consumption is low and it is environmentally friendly.

Flexibility and Easy Installation:

Available in different designs and materials for a variety of applications, fogging nozzles can be easily installed and adapted.

Dust and Odor Control:

It can be used effectively in dust and odor control, which is important for worker health and safety.

High Efficiency:

Thanks to the small droplet size, water evaporates quickly, which increases cooling and humidification efficiency.

Fogging (humidification) nozzles play an important role in many industries and commercial applications with their technical features and wide application areas. These nozzles, which provide effective humidification and cooling by producing fine droplets, are used in many areas from greenhouse farming to animal husbandry, from food storage to dust control. Choosing and using the right fogging nozzle increases the efficiency of businesses, reduces energy costs and improves environmental conditions.

Technicial Specifications

Fogging (humidification) nozzles are special nozzles designed to spray liquids as a fine mist or mist. These nozzles are used to increase the humidity level of the environment or to cool certain areas. The main technical characteristics of fogging nozzles are:

Spray Pattern and Angle:

Fogging nozzles create fog by spraying water in very fine droplets. The spray angle usually varies between 60° and 120°.

Droplet Size:

These nozzles produce very small droplets, usually ranging from 10 microns to 50 microns. Droplet size depends on the design of the nozzle and the working pressure.

Material:

Made from materials such as stainless steel, brass, and plastic (e.g., nylon or polypropylene). The material used is selected according to the application area and chemical

resistance.

Pressure and Flow:

Fogging nozzles generally operate at high pressures (between 20 bar and 100 bar). Flow rate varies depending on the design of the nozzle and the pressure applied, generally ranging from 0.1 liters/minute to 10 litres/minute.

Construction and Design:

These nozzles are designed to ensure that water is forced through very small holes under high pressure, creating a fine mist.
