Blast Freezer

FNO S - Copper Tube: Ø5/8 ", Geometry / 40 mm X 35 mm

Capacity Range: 7 kW - 32 kW

FNN S - Copper Tube: Ø5/8 ", Geometry / 40 mm X 35 mm

Capacity Range: 7 kW - 32 kW

FNO SS - Copper Tube: Ø5/8 ", Geome

Capacity Range: 14 kW - 62 kW

FPN S - Copper Tube: Ø5/8 ", Geometry / 55 mm X 28 mm, Fin Spacing: 4 mm - 6 mm

Capacity Range: 6 kW - 26 kW

FPO SS - Copper Tube: Ø5/8 ", Geometry / 32 mm X 28 mm, Fin Spacing: 4 mm - 6 mm

Capacity Range: 12 kW - 50 kW

FNN SS - Copper Tube: Ø5/8 ", Geometry / 40 mm X 35 mm

Capacity Range: 14 kW - 62 kW

FNO T - Copper Tube: Ø5/8 ", Geometry / 40 mm X 35 mm,

Capacity Range: 7 kW - 32 kW

FNN T - Copper Tube: Ø5/8 ", Geometry / 40 mm X 35 mm

Capacity Range: 7 kW - 32 kW

FPO S - Copper Tube: Ø5/8 ", Geometry / 55 mm X 48 mm

Capacity Range: 6 kW - 26 kW

FPN SS - Copper Tube: Ø5/8 ", Geometry / 55 mm X 48 mm

Capacity Range: 12 kW - 50 kW

FPO T - Copper Tube: Ø5/8 ", Geometry / 55 mm X 48 mm

Capacity Range: 6 kW - 26 kW

FPN T - Copper Tube: Ø5/8 ", Geometry / 55 mm X 48 mm

COIL

• Copper Tubes Ø5/8”"
• “V” type aluminium fins.
• The finned coils are designed with aluminium fins spaced at 10 or 12 mm, crimped onto copper tubes.
• Header inlet and outlet tube connections made of copper.
• Maximum operating pressure PS= 21 bar dor standard products.
• Staggered copper tubes.
• The coil circuits are designed for refrigerants R404A, R449A, R22.
• Refrigerant distributor.

CASING

• Electrostatic powder coated RAL 9016 galvanized steel.
• Stainless steel and aluminum casing as optional.
• Side panels are removeable
• Hinged/Folding drain tray is standart for all models.
• Intermediate drain pan.

OPTIONS

• Different Casing color.
• Other tube wall thicknesses and fin spacing on request.
• HMono phase 220V 1- 50 Hz fan.or three phase 400V 3- 50 Hz fan.
• Please keep in touch with our sales department about your special needs that are not mentioned in the catalogue.
