Steam Boiler

It complies with TS EN 12953, TS 377 standards.

It is high effıcient. it has 90% and more effıciency values.

Its transportation and installation are easy.

It provides package-type manufacturing opportunities. D is ergonomic and easy to use.

With a special design providing maximum heat transfer, it transports the energy obtained as a conclusion of burning to the fluid at the maximum level.

It provides an installation and maintenance facility.

Burning efficiency is high.

It has a large burning cell completely undulated. D Thanks to undulated burning cell, it protects the burning cell against the pressure from outside and the dimension changes arising from extraneous stretching.

AKB-B type cylindrical flame-smoke tube steam boilers have flame recycled two-flow combustion cells. Flame occurred with the fırst flow reversed within the combustion cell. The returned flame burns the unburned fuel and unburned fuel again ensures to obtain good burning at high flame temperature. At the third flow, burnt gases passing through the steam pipes transfer their energy into the water.

In order to occur good combustion (so, high boiler efficiency), burning cell volume is kept at a sufficient size.

The water volume of the boiler is kept as low as possible. So, immediate and sudden steam is obtained.

Heat transfer rates and thermal tensions are distributed homogeneously on the boiler heat transfer surfaces.

The design and manufacturing of AKB-B type cylindrical steam boilers are manufactured y in accordance with TRD, DiN, EN, TS and material norms.

It does not create chimney draft problems since it provides optimum pressure values within the boiler.

Thanks to superior construction and manufacturing technology, the condensations in the boiler can be prevented and the boiler life is prolonged.
