- AZURE Wheel
- AZURE Wheel, ceiling-type compact air handling units are designed for spaces where air quality is crucial, ensuring the removal of stale indoor air while providing fresh air.
- These units feature a high-efficiency SORPTION heat recovery Rotary Wheel for both temperature and humidity control, along with advanced SENSO+ controls, very quiet operation, and easy plug-and-play installation.
- With their ceiling installaiton and service access from both botton and side orientations, they save valuable mechanical space and increase available commercial space, making them a practical choice.
- Optimized in 4 different models with a flow rate range of 350-5500 m³/h.
- A compact design, well-suited for indoor building installation with insulated double wall casing.
- Ensures low operational costs with high temperature and humidity exchange efficiency with Sorption Rotary Wheels.
- Very low unit design thanks to the parallelly designed Rotary Wheels.
- Low internal pressure drop.
- Both botton and side servicing options come as standard.
- Integrated electric pre-heater and electric/water final heaters as accessories inside the units’ casing.
- External accessories for duct-type water or DX coolers.
- Web-based and user-friendly selection software at www.aeraselect.com.
- BIM files available for Revit and MagiCad applications.
Product Details
Technicial Specifications
Other products
About the Company
Contact
CASING
Inner sheets made of AZ 150 Aluzinc.
Outer sheets made of galvanized steel with powder coating
Insulated with 50 mm thick rock wool of 70 kg/m³ density.
Thermal transmittance T2, Thermal bridging class TB2.
High air tightness
HEAT EXCHANGER
Utilizes a SORPTION-type heat recovery rotor achieving up to 89% Enthalpy efficiency at nominal air flows
Proportional rotor speed control unit with 0-100% speed control thanks to its unique step control and drive-belt system.
Provides free cooling for enhanced energy efficiency.
Secures a robust airtightness between fresh air and exhaust air streams, enhancing overall system performance with unparalleled precision.
FAN
Superior aerodynamic efficiency.
Low noise levels and energy consumption.
Plug fans with IE4 efficiency class EC motors.
Fan selection in compliance with ECO-DESIGN criteria.
AC-powered, DC motor technology for speed control.
FILTER
ECO-DESIGN compliant ePM1 55% (F7) class filter on the fresh air side, and ePM10 50% (M5) filters on the exhaust side, as standard.
Dynamic filter cloaking measurement.
Optional use of ePM1 80% (F9) filter for enhanced filtration performance.
PLUG-PLAY
Design-in every aspect
Integrated controls.
Simplified installation.
Swift commissioning.
Adjustable base feet for precise balancing.
CONTROLS & CONNECTIVITY
Constant air volume (CAV), variable air volume (VAV), and demand-controlled ventilation (DCV) options.
Optional indoor air quality control
Temperature control.
Humidity control.
Standard Bacnet IP or Modbus TCP/IP BMS connections, with future connectivity option LONWORKS
www.AERACLOUD.com Cloud Access
Dry contact communication with fire alarm panel.
