Range of low profile in-line mixed flow duct fans manufactured in tough reinforced plastic (from 160 to 2000 models) or with metal casing steel finished in a tough epoxy-polyester paint coating (for models 4000 and 6000).
The unique design of the support bracket allows the motor and impeller assembly to be fitted or removed without dismantling the adjacent ducting.
Motors
Models 160-2000:
Class B, with ball bearings and safety thermal overload protection. IP44.
Direct 2 or 3 speed connection and also suitable for voltage speed control.
Electrical supply:
Single phase 230V-50Hz. (models from 160 to 350)
Single phase 230V-50/60Hz. (models from 500 to 2000)
Models 4000 and 6000:
Class F, with ball bearings and safety thermal overload protection. IP54.
Suitable for voltage speed control.
Electrical supply:
Single phase 230V-50/60Hz.
Three phase 400V-50/60Hz (model 4000) or 400V-50Hz (model 6000)
TD-MIXVENT-T models
TD-MIXVENT versions fitted with a run-on-timer adjustable within 1 and 30 minutes and 1 or 3 speed motor (depending on the model) not suitable for speed control.
