Heat Recovery Unit

Range of domestic MVHR units with high efficiency counterflow heat exchanger (up to 92%) and low consumption EC motors.

The units assure a continuous and balanced ventilation system, extracting moist stale air from the wet rooms and at the same time introducing a tempered and filtered fresh air to the habitable rooms.

The optimized design allows compliance with the highest standards assuring a very low leakage level, high thermal insulation and a minimal sound level.

The integrated humidity sensor allows an automatic function tracking the indoor humidity and proportionally adjusting the fans speed.

The unit contains as a standard iso coarse 65% (G4) filters in the supply and extract airflows to clean the incoming air and protect the heat exchanger.

For higher air quality an optional Pm1 70% (F7) filter can be installed in the supply air channel.

An integrated 100% bypass is activated either automatically or manually.

The bypass is particularly useful when the indoors temperature is higher than outdoors and free cooling is preferable.

INSTALLATION FRIENDLY

A versatile product with advantages for installation.

The airflow direction paths can be handed to allow for alternate on-site configurations of duct routing.

A range of accessories lets the end user tailor the functions of the system to their specific requirements.

Characteristics:

- High efficieny counterflow heat exchanger

- Low consumption EC motors

- Minimal sound level

- Automatic/manual bypass

- Install friendly

- User friendly

- Customisable

Optional accessories:

- Integrable pre heater

- Integrable VOC sensor

- Communication module

- Integrable constant airflow module (Servoflow)
